SOHAM ENTERPRISE
CP PLUS 1080 4 Channel HD DVR (CP-UVR-0401E1-IC /CV2/ CV5)
CP PLUS 1080 4 Channel HD DVR (CP-UVR-0401E1-IC /CV2/ CV5)
Regular price
Rs. 3,299.00
Regular price
Sale price
Rs. 3,299.00
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Power and Connectivity Features
Network Interface Type
1 RJ-45 port (10/100Mbps)
Number of USB Ports
2
USB Type
2
Number of Ethernet Ports
1
Audio Interface
G.711A, G.711U, PCM
Alarm Interface
Video recording, snapshot, log, preset, tour
Other Connectivity Features
HTTP; HTTPS; TCP/IP; IPv4/IPv6; 3G/4G; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; InstaOn cloud; IP Search, ONVIF 16.12, CGI Conformant
Power Requirement
DC12V/1.5A
Power Consumption
7 W
Other Power Features
<7W (without HDD)
In the Box
1 DVR
General
Brand
CP PLUS
Model Number
CP-UVR-0401E1-IC2
Type
Digital Video Recorder
Product Type
Standalone
Number of Channels
4
Camera Type
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Video Output
1 HDMI, 1 VGA HDMI/VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Video Recording Resolution
5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF
Video Recording Frame Rate
25fps/30fps
Additional Features
Alarm Action
Human Body Detection Support the classification and accurate detection of human & Motor Vehicle
Mobile Compatibility
iPhone, iPad, Android Phone
Application Support
gCMOB, iCMOB, KVMS Pro Lite
Operating Temperature
-10°C ~ +45°C (+14°F ~ +113°F), 10 ~ 90% RH degree C
Other Convenience Features
IE, Chrome, Firefox
Material
Metal
Model Name
4Ch. DVR 1080N Digital Video Recorder (CP-UVR-0401E1-IC2)
Color
Black
Mounting Type
Wall Mount, In a Rack, Flat Surface
Key Features
Supports HDCVI/AHD/TVI/CVBS/IP video inputs, Supports Full-channel AI Instastream, Instastream/H.265 dual-stream video compression, Support 1 SATA HDD up to 6TB Each, 2 USB Ports
Dimensions
Width
198 mm
Height
203 mm
Depth
41.5 mm
Weight
570 g
Product Details
Video Formats
1080N; 720P; 960H; D1; CIF
Recording Formats
Main Stream: All channels 1080N/720P/960H/D1/CIF/(1~25/30fps) Sub stream: CIF (1~15 fps)
Display Frame Rate
25/30fps
Record Modes
Auto
Other Video Features
Playback Play, pause, stop, fast forward, fast backward, rewind, play by frame, Full screen, backup (cut/file), partially enlarge, audio on/off, Embedded processor
HDD Available
No
HDD Type
SATA
System Requirements
DVR
Other Performance Features
1 SATA port, up to 6TB Each
Compatible Devices
MonitorMobilePC/Laptop
Power Source
DC
Remote Connectivity
Lan CableWi-FiCloud
Remote Pan & Tilt
Pan & Tilt
Smart Home Integration
Google Assistant
Sound Triggered Recording
Yes
Audio Output
Speaker & Microphone
Storage Type
HDD
USB Port Present
Yes
Cry Detection Sensor
No
Camera Resolution
2 mp
HDD Capacity
6
Night Vision
Yes
Maximum Record Time
24 hr
Remote Control
